Hikvision DS-2XC3386G0H-LISU/SL (PA) 8MP 4K Anti-Corrosion AcuSense Turret Camera
The Hikvision DS-2XC3386G0H-LISU/SL (PA) is a professional
8MP 4K anti-corrosion turret network camera designed
for demanding outdoor environments where conventional security
cameras may be exposed to salt, moisture and corrosive conditions.
Featuring a specialised polymer anti-corrosion housing,
this Hikvision security camera provides
C5 and NEMA 4X corrosion protection, IP68 weather resistance
and IK10 impact protection, making it particularly suitable
for coastal properties, marine facilities, industrial sites
and chemical processing environments.
Its advanced 1/1.8-inch CMOS sensor delivers
8MP Ultra HD 4K resolution at 3840 × 2160 pixels,
providing detailed surveillance footage for professional
CCTV security installations.
The camera combines Hikvision AcuSense human and vehicle
classification, Smart Hybrid Light, 120dB WDR, two-way audio,
active strobe-light and audible warning functions
to provide intelligent monitoring and active security deterrence.
With up to 30 metres of supplementary illumination,
efficient H.265+ compression and PoE connectivity,
the DS-2XC3386G0H-LISU/SL (PA) is a reliable solution
for professional surveillance in challenging environments.
Key Features
-
8MP Ultra HD 4K Resolution: High-quality imaging at 3840 × 2160 pixels.
-
Advanced Anti-Corrosion Protection: C5 and NEMA 4X ratings for demanding environments.
-
Polymer Housing: Corrosion-resistant construction for coastal and industrial applications.
-
IP68 Weather Protection: Enhanced resistance to dust and water ingress.
-
IK10 Impact Protection: Robust construction for exposed installations.
-
Smart Hybrid Light: Intelligent infrared and white-light illumination up to 30m.
-
Hikvision AcuSense: Deep-learning human and vehicle classification.
-
Active Deterrence: Integrated flashing light and audible warning functions.
-
Two-Way Audio: Built-in audio capabilities for communication and monitoring.
-
120dB WDR: Improved imaging in challenging lighting conditions.
-
F1.0 Aperture: Enhanced low-light image capture.
-
Lens Options: Available with 2.8mm or 4mm fixed lens.
-
H.265+ Compression: Efficient video storage and bandwidth management.
-
PoE Connectivity: Compatible with IEEE 802.3af PoE equipment.
-
Professional NVR Integration: Compatible with supported Hikvision recording systems.
Technical Specifications
| Model |
DS-2XC3386G0H-LISU/SL (PA) |
| Camera Type |
Anti-Corrosion Fixed Turret IP Camera |
| Resolution |
8MP / 3840 × 2160 / 4K UHD |
| Image Sensor |
1/1.8" Progressive Scan CMOS |
| Lens Options |
2.8mm or 4mm Fixed Lens / F1.0 |
| Field of View |
2.8mm: 108.8° Horizontal / 4mm: 93.3° Horizontal |
| Night Illumination |
Smart Hybrid Light / IR & White Light / Up to 30m |
| AI Detection |
Human & Vehicle Classification |
| Active Deterrence |
Strobe Light & Audible Warning |
| Audio |
Built-in Two-Way Audio |
| Wide Dynamic Range |
120dB WDR |
| Video Compression |
H.265+ / H.265 / H.264+ / H.264 |
| Corrosion Protection |
C5 / NEMA 4X / Polymer Housing |
| Environmental Protection |
IP68 / IK10 |
| Operating Temperature |
-30°C to +60°C |
| Power Supply |
12V DC / IEEE 802.3af PoE / Max. 9.5W via PoE |
Detailed Features & Benefits
Advanced C5 Anti-Corrosion Protection
The Hikvision DS-2XC3386G0H-LISU/SL (PA) is engineered
for installations where airborne salt, moisture
and corrosive environmental conditions
create additional challenges for conventional CCTV cameras.
Its specialised polymer housing provides
C5 and NEMA 4X anti-corrosion protection,
making it particularly suitable for marine facilities,
coastal buildings, docks, industrial installations
and chemical processing environments.
This specialised construction helps improve durability
in locations where standard camera housings
may be more vulnerable to corrosion.
8MP 4K Ultra HD Surveillance
The camera features a
1/1.8-inch progressive scan CMOS sensor,
delivering high-resolution 8MP images
at up to 3840 × 2160 pixels.
Its 4K resolution provides detailed video
for monitoring building entrances, industrial equipment,
loading areas and outdoor facilities.
The large sensor and F1.0 aperture also support
improved imaging in challenging lighting conditions.
Smart Hybrid Light with 30m Illumination
Hikvision Smart Hybrid Light combines
infrared and white-light illumination
to support different night-time monitoring requirements.
The camera provides supplementary illumination
up to 30 metres,
allowing installers to configure suitable
night-time surveillance behaviour.
Infrared illumination supports discreet
black-and-white monitoring, while white light
can provide additional illumination
for colour surveillance.
AcuSense Human and Vehicle Detection
Hikvision AcuSense technology uses deep-learning
analytics to classify human and vehicle targets
in supported security detection scenarios.
This helps reduce unnecessary alerts caused
by unrelated movement and allows security
operators to focus on relevant activity.
Supported perimeter protection functions include
line crossing, intrusion, region entrance
and region exiting detection.
Active Strobe Light and Audible Alarm
The DS-2XC3386G0H-LISU/SL (PA) includes
active visual and audible deterrence
capabilities.
When supported detection events are triggered,
the camera can activate its flashing light
and audible warning functions
according to the configured security rules.
These features can help provide immediate
warnings around restricted areas,
commercial entrances and industrial facilities.
Built-In Two-Way Audio
Integrated two-way audio allows supported
security systems to provide real-time
audio communication through the camera.
This can be useful for communicating
with visitors, contractors or personnel
at monitored entrances and access points.
Audio functions require compatible
equipment, network access and configuration.
IP68 Weather Resistance and IK10 Impact Protection
The camera features an
IP68-rated enclosure,
providing enhanced protection
against dust and water ingress
under specified test conditions.
Its IK10 impact rating
provides additional protection
against mechanical impacts.
These features make the camera
particularly suitable for exposed
outdoor installations requiring
robust environmental protection.
Efficient H.265+ Video Compression
Hikvision H.265+ compression helps
optimise video storage requirements
and network bandwidth.
This is particularly beneficial
for professional CCTV systems
recording high-resolution 4K footage
to compatible network video recorders.
Ideal Applications
-
Coastal Properties: Security monitoring in salt-air environments.
-
Marinas and Docks: Surveillance of marine facilities and waterfront infrastructure.
-
Ports and Shipping Facilities: Monitoring exposed operational areas.
-
Chemical Plants: Surveillance in suitable corrosive industrial environments.
-
Industrial Facilities: Monitoring equipment, entrances and operational areas.
-
Wastewater Facilities: Security monitoring in challenging environmental conditions.
-
Commercial Buildings: Outdoor surveillance requiring enhanced corrosion protection.
-
Outdoor Storage Areas: Monitoring valuable equipment and materials.
Compatibility & Installation
The Hikvision DS-2XC3386G0H-LISU/SL (PA)
is designed for professional IP CCTV installations
and integration with compatible Hikvision NVRs
and video management platforms.
The camera supports standard
IEEE 802.3af PoE
or a suitable 12V DC power supply.
Professional installers should select
suitable corrosion-resistant mounting hardware,
protected network connections and compatible
recording equipment for the installation environment.
The required lens should be selected
before ordering. The 2.8mm version
provides a wider horizontal viewing angle,
while the 4mm version offers a narrower
field of view.
Camera compatibility, intelligent analytics,
audio functions and active deterrence
should be verified against the selected
recording system and firmware.
Package Includes
-
1 × Hikvision DS-2XC3386G0H-LISU/SL (PA)
8MP Anti-Corrosion Turret Network Camera
Please note:
Lens configuration depends on the selected variant.
NVR, hard drive, network cabling, additional
mounting accessories, external power equipment
and installation services are not included
unless specifically stated.
Confirm supplied accessories and optional
storage against the exact product SKU.
Frequently Asked Questions
What makes this Hikvision camera anti-corrosion?
The camera features a specialised polymer housing
with C5 and NEMA 4X anti-corrosion protection,
making it suitable for demanding environments
such as coastal locations and industrial facilities.
Is the DS-2XC3386G0H-LISU/SL (PA) suitable for coastal installations?
Yes. Its anti-corrosion construction is designed
for demanding environments exposed to salt
and moisture. Suitable mounting hardware
and correct installation remain essential.
Does this camera record in 4K?
Yes. The camera supports 8MP Ultra HD
resolution at 3840 × 2160 pixels.
Maximum frame rate depends on the
selected recording settings.
Does the camera support human and vehicle detection?
Yes. Hikvision AcuSense technology supports
intelligent human and vehicle classification
for applicable security detection functions.
Does this camera have an alarm and flashing light?
Yes. The /SL version supports active
strobe-light and audible warning functions
that can be configured for supported events.
Can this camera be powered by PoE?
Yes. The camera supports IEEE 802.3af PoE
or a compatible 12V DC power supply.
What lens options are available?
The camera is available with a 2.8mm
or 4mm fixed lens. Confirm the required
lens version before ordering.
